SELF ADHESIVE FLAT CABLE CLAMP

Applications

For supporting & holding flat cable

Key Industries:

Automobile

Electrical / Electronics

Telecom

White Goods & Appliances

Windmill

Line Drawing - Self Adhesive Round Cable Clamp

End Application - Self Adhesive Round Cable Clamp

Specifications

Material: Nylon 6: UL 94 V-2 (backed with adhesive tape)
Color: Natural Clip Support
Operating Temp: -29°C to +49°C (Max. Intermittent Temp. i.e. less than 2 hrs. 70ºC)
Packing: 100 Pcs. bag
Unit: 100 Pcs/Pkt

Tolerance:
Length: ±1mm
Width: ±1mm
Height: ±3mm
Mounting Hole: ±0.6mm

Features

* Low profile & flexible top allows easy removal & replacement of desired cables
* Rubber based closed cell foam adhesive is used for better surface adhesion
* Holds single or multiple layers of flat ribbon cable neatly & firmly

How to use:
* To apply, simply peel off the backing paper and apply mount to any clean smooth, grease-free surface
* Place flat ribbon cable in nylon clamp

Download Brochure

Description

Adhesive Tape

L Length (mm)

B Width (mm)

C Height (mm)

Mounting Hole (mm)

Cat No.

PDF Drawing

Clip Support

3M Green

25.0
