NYLON 'P' CLIP PERFORATED ADJUSTABLE

Applications

Most versatile clamp to hold cable, tubes, components

Key Industries:

Electrical / Electronics
White Goods & Appliances
Nylon P Clip Fix and Adjustable
Nylon P Clip Fix and Adjustable Line Drawing - P Clips Perforated Adjustable End Application - P Clips Perforated Adjustable

Material: Nylon 6: UL 94 V-2
Color: Natural
Operatig Temp: -40°C to +85°C
Packing: 100 Pcs. bag
Unit: 100 Pcs/Pkt

Tolerance:
Width: ±1mm
Height: ±0.5mm
Suitable Dia: ±1mm

* Perforated design allows wide range of cable diameters clamping
* Easy mounting with screw
Download Brochure
Size No. Suitable for Wire O.D. (Inch/mm) Width (mm) T Thickness (mm) H Hole (mm) Cat No. PDF Drawing
No. I Adjustable 1/2 (4 to 12.5) 9.00 1.20 3.00
PCH-12
No. II Adjustable 5/8 (6 to 15.8) 11.10 1.35 5.95
PCH-15
No. III Adjustable 1 (15 to 25) 12.00 1.40 5.50
PCH-25
No. IV Adjustable 1 1/2 (28 to 56) 12.50 1.25 4.75
PCH-50
No. V Adjustable 2 1/2 (35 to 62.5) 12.60 1.50 4.80
PCH-62
