DOOR LOCK SEAL

Applications

Transport Vehicle doors of courier, postal dept., warehouse vans, container-cargo truck doors, trailers and other such applications

Key Industries:

Door Lock Seal Manufacturer
Door Lock Seal Manufacturer Line drawing - Door Lock Seal Door Lock Seal

Material: Polypropylene and POM for insert
Color:
* Red, Yellow, Blue, Green, Orange, White are standard colors
* Other colors available upon request
Operating Temp: -40°C to +85°C
Marking:
* Since there is no provision of marking Tag the laser printing can be done on the plain surface of the security seal length
Installation: No tool required
Test Certificate:
Packing: 100 pcs bag in all sizes
Unit: 100 Pcs/Pkt

* The locking device in the seal ensures 100% tamper evident application with two point positive locking. When the strap is inserted, the lock housing becomes completely enclosed.
* Cap is securely ultrasonic welded and tampering can be ascertained by visual inspection
* Easy to close and break
* Hot stamping/laser printing can be done on the plain surface of the security seal length.
* No tool required for installation

Size LxW (mm) Material Tensile Strength Kgs (lbs) Max. Bundle Dia (mm) Marking Space on Front (L x W) Marking Space on Back (L x W) 100 Pcs. Pack Cat. no. PDF Drawing
200 x 8 POLYPROPYLENE 20 (44) 54 100 x 5 100 x 5
SSDL-200P
260 x 8 POLYPROPYLENE 20 (44) 73 100 x 5 100 x 5
SSDL-260P
300 x 8 POLYPROPYLENE 20 (44) 86 100 x 5 100 x 5
SSDL-300P
